A fully-integrated, high-brightness LED Ringlight designed to fit a wide range of light microscopes. No external controller is required and LED adjustment includes options to switch sections on and off and rotating the selected segments. This allows homogeneous illumination as well as directed lighting – the resulting shadows offer excellent contrasting options for surface structures.
Features
- Fully-integrated control – no controller box required
- Ergonomic operation
- High-brightness – homogeneous spot
- Adjustable working distance (45-130mm and 80-300mm)
- Continuous dimming from 1 – 100% (flicker-free)
- Individual segment control
- Autorotation with variable speed
- High quality, scratch resistant varnish
- Passive cooling with minimum heat generation
- Reproducible settings and comprehensive functions
- Right and left-hand operation
Light diffuser, polarisation filters and adapters are available as optional extras.
Polarising filter set
- consists of polariser and analyser filters
- reflections are suppressed
- ideal for reflecting surfaces
Diffuser
- generation diffused light
- homogeneous, shadow-free illumination
Adapters – various diameters available
- 66/58mm for Ringlight 66mm to 58mm dia lens
- 66/60mm for Ringlight 66mm to 60mm dia lens
- 66/62mm for Ringlight 66mm to 62mm dia lens
- M48 x 0.75mm for Ringlight 66mm to thread M48 x 0.75
- M55 x 0.75mm for Ringlight 66mm to thread M55 x 0.75
