EYEPIECES
Pair of DIN HWF Plan 10x/22 mm eyepieces
NOSEPIECES
Revolving quintuple nosepiece on ball-bearings
HEADS
Trinocular 45° inclined tubes with extended low and high positions for eyepieces.
One diopter adjustment on left eyepiece.
Interpupillary distance of 54 to 75 mm.
Trinocular head with 100-0 % and 80-20 % positions
OBJECTIVES
Infinity color corrected long working distance 5x/0.15, 10x/0.14, 20x/0.45 plan achromatic IOS objectives and a plan semi apochromatic S50x/0.55 IOS objective.
All optics are anti-fungus treated and anti-reflection coated for maximum light troughout
STAGE
Large stage 250 x 230 mm equipped with a coaxial mechanical 120 x 78 mm X-Y stage, delivered with:
– metallic insert standard with Ø 12 mm diameter hole and Ø 25 mm diameter hole
– metallic insert with hole for mechanical stage
CONDENSER
Abbe condenser with iris diaphragm
FOCUSING ADJUSTMENT
Coaxial 25 mm coarse and fine adjustments, 2 µm precision and with friction adjustment
ILLUMINATION
Transmitted Köhler 50 W halogen Intensity adjustable with internal 100-240 V power supply. Fuse holder 3.15 A / 250 V
POLARIZATION
Standard polarization filter and 360° rotating analyzer
FILTERS
Standard blue and green filter
Instruction manual and dust cover included
Size: (h) 488 mm, (w) 231 mm, (d) 555mm
Weight: 10.8 kg
