TECHNICAL SPECIFICATIONS
Sensor
Sony 4K sensor
Format
1/1.8” (7.68 x 4.32)
Pixels
3840 x 2160 pixels, HDMI 1.4 standard,
30fps@4K or 30fps@1080P;
Pixel size
2.0 x 2.0 μm
Video recording
8.3 MP (3840 x 2160) H264/H265 encoded MP4 file
Image capture
8.3 MP (3840 x 2160) JPEG/TIFF image in SD card
HD screen (VC.3045-HDS)
13”
Scan mode
Progressive scan, rolling shutter
Sensitivity
3154 mv
Noise
standard noise reduction
Exposure
Automatic/ manual
White balance
Manual/ Auto/ ROI White Balance
Interface
HDMI, USB-2
Storage
32 GB, SD card included (max. 128 GB)
Camera buttons On/ Off
Mounting
C-mount
Power supply
DC 12V/1A adapter
Humidity
30~80%RH
Operation temperature
-10~ 50°C,
Storage temperature
-20~ 60°C
Supplied with
0.5x objective with C-mount, 30 and 30.5mm adapters for stereomicroscopes, 12V/1A power adapter, HDMI cable, USB mouse , SD-card, USB-3 cable (a male to male), 76 x 24 mm calibration slide (1mm/100), CD ROM with ImageFocus Alpha software, user manual, carton box
PC software
Supplied with ImageFocus Alpha imaging and measuring software for Windows 7/ 8/ 10 (32 and 64 bit configurations) and Linux. A Mac OS version is also supplied (with a few differences in features)
PC requirements
Equal to Intel Core 2, 2.8 GHZ or higher, 2 GB memory, USB-2
Product number
VC.3045 / VC.3045-HDS
