• Head: binocular, 30° angled, rotating 360°
  • Eyepieces: WF10x / 20mm
  • Pupillary distance: between 48-75mm
  • Diopter adjustmet: +/-5D on the left eyepiece tube
  • Nosepiece: 4 step
  • Objectives:

Semi-Plan 4x / 0:10
Semi-Plan 10x / 0:25
Semi-Plan 40x / 0.65, spring,
Semi-Plan 100x / 1.25, spring, oil immersion

  • Total magnification: 40x, 100x, 400x, 1000x
  • Focusing: coaxial coarse and fine adjustment
  • Stage size: 130x130mm, X, Y directions to move
  • Stage movement: 70 x 27 mm
  • Condenser: Abbe N.A. 1.25, iris aperture, filter holders, high adjustable
  • Illumination: Köhler system, 1W NeoLED with brightness control,
  • Rechargeable battery: 3xAA
  • Accessories in the package: dust cover, 5 ml immersion oil, user guide
  • Size: (h) 360 x (w) 155 x (d) 230 mm
  • Weight: 4 Kg
