Head:
- trinocular head, 45° inclined, 360° rotatable
Eyepieces:
- WF 10x/22 mm, can be used with glasses
- Diopter adjustment: +/-5D, both eyepieces
- Eyedistance adjustment: 52mm – 75mm
Objective:
- Zoom ratio: 1 : 6.3
- Zoom : 0.8 – 5.0x,
- Total magnification: 8-50x
- Field of view: 27mm-4.4mm
Focus system:
- Focusing system: coaxial coarse and fine focusing adjustment
- The inside diameter of the focusing arm: 76 mm
- Working distance : 115 mm
- Focusing Range: 50 mm
Illumination:
- incident and transmitted LED reflector, mirrored cage system
Accessories in the package:
- dust cover
- user manual
- 100 mm glass holder
- Subject Clamping Clips
Product information:
- Stand size: base 280 x 180 mm x 61 mm, tube height: 250 mm, diameter: 32mm
Weight: 4 Kg
