Head:

  • trinocular head, 45° inclined, 360° rotatable

Eyepieces:

  • WF 10x/20 mm, can be used with glasses
  • Diopter adjustment: +/-5D, both eyepieces
  • Eyedistance adjustment: 52mm – 75mm

Objective:

  • Zoom ratio: 1 : 4.5
  • Zoom : 1 – 4.5x
  • Total magnification: 10-45x
  • Field of view: 22mm-5mm
  • Working distance : 97 mm

Focus system:

  • Focusing system: coaxial coarse and fine focusing adjustment
  • The inside diameter of the focusing arm: 76 mm
  • Focusing Range: 50 mm

Illumination:

  • incident and transmitted LED reflector

Accessories in the package:

  • dust cover
  • user manual
  • 100 mm glass holder
  •  Subject Clamping Clips

Product information:

  • Stand size: base 280 x 180 mm x 61 mm, tube height: 250 mm, diameter 32 mm
  • Weight: 4 Kg
